i4 LAB
(Innovation Integration Incubation & Implementation)


"Learn while Innovating or Innovate while Learning"

A random idea might lose its track if it is not nurtured regularly in the right way. For a large number of people venturing into the culture of entrepreneurship nowadays, it is very important to educate and support them for the proper growth of their ideas. At AIC-RNTU, we have taken the charge of providing essential services such as fund support, management, mentorship, co-working space, and state-of-the-art technical assistance to the budding business units. And providing a platform to students, entrepreneurs, professionals to fabricate the samples, build a prototype in our lab with their ideas. And assistance throughout the way by our team. By playing the role of both startup incubator and accelerator, we aim at training and mentoring young people to fuel their inner drive to innovate. Our primary objective here is to create a startup ecosystem and familiarize the visionary brains with the business aspects of an idea and provide them with a platform with necessary resources – culture, opportunities, and amenities – to grow their startup units into business enterprises.

Resources

3D Printer

Technical Specifications


Application :         FDM/FFF.         Nozzles:         2 (0.4mm Default) .
Model Materials :         PLA, PVA, ABS, TPU, HIPS, Flexible.     File Type :         STL, OBJ, G-code .
Layer Resolution :         60-300 um .     Dedicated Software :         Fracktory .
Max. print size :         350 x 400 x 400 mm .     File Type :         STL, OBJ, G-code .
Heated Chamber :         Yes (possived) .         Power Input :         240v, 60Hz 1250W .
Camera :         Yes .         Interface:         Touch HMI .
Heated Bed :         Yes (120°C) .         Connectivity :         USB, Wifi, Ethernet .
Filament Sensor :         Yes .         IMEX* :         Yes.

3D printer can print solid 3D models which are simple or complicated ranging from toys to bearings, machine parts, replacements of broken article, casing and variety of other things. 3D printer helps turn concepts and ideas into physical prototypes saving time, reducing costs and shortening product development life cycles


LASER Machine

This machine are used for engraving and cutting on wooden material, acrylic and other soft materials.

Technical Specifications

Application :         Laser Cutting and Laser Engraving.
Technology :         Hermetic And Detached Co2 Laser Tube .
Machine Control and Drive :         Speeded DSP controlling stepper motor .
Materials :         Acrylic, Wood, MDF, Paper etc. .
Rated Power :         1-3kw .
Resoultion :         Upto 300 mm/s .
Cutting Speed :         1 - 100 mm/s .
Dedicated Software :         RD Works .
connectivity:         USB .

Resources

Resources

CNC Router Machine

This CNC Router machine can engrave the 3D & 2D design on wood, plywood, MDF board and Acrylic also. Its working precision is very high.

Technical Specifications

Uses/Applicale:         Wood Cutting Encraving.
Workpiece table Size :         1300 x 2500 x 200 mm .
Power Consumption :         7 KW .


MINI 3D Printer

This printer is Digital Light Processing (DLP) type. Its output is very precise than other type of 3D Printer. It can design very complex model quickly and easily.

Technical Specifications

Application :         Layer projection system .
Technology :         Hermetic And Detached Co2 Laser Tube .
MBuild size :         130 (W) x 70 (D) x 70 (H) mm .
Build speed :         12 mm/h (Layer pitch = 0.15 mm)* .
XY resolution :         UV- LED (ultraviolet light emitting diode) .
Z axis resolution :         0.01mm .
Power requirements :         DC 24 V, 0.6 A | AC 100 V to 240 V | 50/60 Hz .
Power Consumption :         15 KW .
Dedicated Software :         RD Works .
connectivity:         USB .
Dimension/Weight :         430 (W) x 365 (D) x 450 (H) mm / / 17 kg .
File type :         STL .
Dedicated Software:         monoFab Player AM .

Resources

Resources

Mini CNC Machine

As a small milling machine, that offers compact size and powerful functionality. Production of realistic parts and prototypes is made simple. For users looking for advanced milling capabilities without the need for expert operating skills, this is one of the easiest and most precise CNC mills in its class.

Technical Specifications

Cuttable Material :         Modelling Wax, Chemical Wood, Foam, Acrylic, Polyacetate, ABS, PC board.
X, Y, and Z Operation Strokes:         203.2 (X) x 152.4 (Y) x 60.5 (Z) mm .
Workpiece table size . :         232.2 (X) x 156.6 (Y) mm.
Loadable Workpiece Weight:         2kg .
Operating Speed :         6 - 1800mm/min .
Mechanical Resolution:         0.000998594 mm/step .
Control Command Sets :         RML-1, NC code .
Power requirements :         DC 24V, 2.5A, | AC 100-240 V ±10%, 50/60 Hz .
Power consumption:         50 W .


Vinyl Cutter

It is a type of computer-controlled machine. The computer controls the movement of a sharp blade over the surface of the material. This blade is used to cut out shapes and letters from sheets of thin self-adhesive plastic (vinyl). It is used to make signs, banners and advertisements. Advertisements seen on automobiles and vans are often made with vinyl cut letters.

Technical Specifications

Driving method :         Digital control servo motor .
Cutting method:         Media-moving method .
Acceptable media :         50 - 700 mm (2 to 27.5 in.) .
Max. cutting area:         Width: 584 mm (22.9 in.)Length: 25 m (984 in.) .
Acceptable tool:         Special blade for CAMM-1 series.
Max. cutting speed:         500 mm/s (all directions) .
Cutting speed:         10 - 500 mm/sec (4 in to 19.69 in/s) (all directions) .
Blade force :         30 - 350 gf .
Mechanical resolution:         0.0125 mm/step.
Software resolution:         0.025 mm/step.
Distance accuracy*1 :         Error of less than ±0.2 % of distance travelled, or ±0.1 mm, whichever is greater.
Repetition accuracy*1*2:         ±0.1 mm or less .
Interface:         USB 2.0.
Replot memory:         2MB .
Power supply :         Dedicated AC adapter Input: AC 100 to 240 V ±10 % 50/60 Hz 1.7 A Output: DC 24 V, 2.8 A .
Power consumption:         Approx. 30 W (including AC adapter) .
Acoustic noise level during operation:         70 dB (A) or less (according to ISO 7779) .

Resources

Resources

3D Scanner

This 3D Scanner can scan real objects for 3D printing. The lightweight, ergonomic design makes it portable and easy to use for larger objects. It can produce portable as well as high-accuracy scans.

Technical Specifications

Technology :         Layer projection system .
Field Of View :         Horizontal 45 deg,Vertical 57.5 deg,Diagonal 69 deg. .
Maximum Power Consumption :         5.0 VDC .
Scan Volume Min:         0.2 m x 0.2 m x 0.2 m .
Scan Volume Max:         2 m x 2 m x 2 m .
Dimensions :         17.8 cm x 12.9 cm x 3.3 cm .
Depth Image Size:         640 px (w) x 480 px (h) .
Operating Temperature :         10 - 40 deg C .
Data Interface:         USB 3.0 .
USB Cable Length:         2 m .
Maximal Image Throughput :         30 fps .
Color Image Size:         1920 px (w) x 1080 px (h) .
RAM:         4 GB minimum.
Screen Resolution:         1280 x 1024 minimum .
Available Hard Disk Space :         2 GB .
